DP-01
Aluminium door – aluminium panel infillAluminium panel door
Doors · 1 leaf, solid aluminium panel
EssentialKES 16,200
Select · recommendedKES 23,800
ModernKES 38,200
Indicative starting price for the smallest standard size, excluding VAT and installation. Confirmed after site measurement.
- Standard sizes
- 900 × 2100 mm
- Typical location
- Kitchen back door, store, DSQ
- Material & construction
- Frame & leaf: Aluminium alloy 6063-T5/T6 extrusions. Infill: aluminium panel – ribbed/flat aluminium sheet or 4 mm aluminium composite panel (ACP), both faces.
- Specification
- System: aluminium door stiles & rails 45 mm deep, wide stiles ~100 mm, mid/kick rail; 44.5 × 101.6 mm (1¾" × 4") frame; wall 1.6–2.0 mm. Infill: 4 mm ACP or 1.2–1.5 mm ribbed aluminium sheet, gasket-glazed; weatherproof, no glass. Finish: polyester powder coat 60–80 µm (black, charcoal grey, bronze, white) or silver anodised.
- Hardware & consumables
- 3 heavy-duty butt hinges per leaf (4 if leaf > 2100 mm); mortice lock with euro cylinder + 3 keys; lever handle set; floor door stop; flush bolts top & bottom on inactive leaf (double doors); EPDM gaskets; brush or drop-down threshold seal; aluminium threshold plate; frame anchors at ≤ 600 mm; packers; silicone sealant; door closer optional. ACP/aluminium sheet panel; panel gaskets; security hinge bolts.
